The VC high-speed mixer is a new mixing equipment developed by our company based on advanced technology. It enhances the mixing efficiency, enabling the particles to be fully mixed and dispersed, and achieving uniform mixing at the micron level. It has a wide range of applications, such as strong mixing of slurries, liquids, and powders, as well as ball formation, dispersion, drying, granulation, and coating.
The product is fed into the device through the top of the conical mixing chamber, with the feeding range being between 30% and 100%. There is a high-speed rotating shaft at the top of the equipment, which eliminates the sealing design and bearings in the product area. On the shaft, there are paddle-type mixing components that are closely attached to the inner wall. Through the combined action of the high-speed rotating stirrers and the conical inner chamber, the product is transported from the bottom to the upper part of the mixing chamber. When the product reaches the top, it falls back to the center of the mixing chamber. This method of product transportation forms a rapid macroscopic mixing.
Application of VC High-speed Mixer:
1. Battery industry (positive and negative electrode materials)
2. Mixing powders and slurries with high viscosity;
3. Moist powder materials;
4. Package;
5. Granulation.
Characteristics of VC High-Speed Mixer
1. The mixing efficiency is high, the effect is excellent, and the rotational speed is fast, reaching up to 1440 revolutions per minute.
2. The body of the bucket is very easy to clean thoroughly.
3. The product lacks bearings or seals, resulting in a long equipment maintenance period.
4. Vacuum operation and spray wetting can be selected.
5. Since the entire cavity is protected by a jacket, the temperature can be precisely controlled. The stirring shaft is located at the top, which can prevent local overheating. It has a wide range of applications, such as strong mixing, dispersion, crushing, drying, granulation and coating of slurries, liquids and ultrafine powders.
6. It can be heated. Heating methods: electric heating, water heating, and gas-oil heating are all available.
